Explanation:
FCAPS -> Fault, Configuration, Accounting, Performance and Security (ISO)
ITIL -> A collection of best practice recommendations
Cisco Lifecycle -> Often referred to as the PPDIOO model
TMN -> Telecommunications Management Network
Well Known Network Maintenance Models
Maintenance models
Model
Explanation
FCAPS
Fault-, Configuration-, Accounting-, Performance- and Security management defined by ISO
ITIL
IT Infrastructure Library
Defines a collection of best-practice recommendations that work together to meet business goals.
TMN
Telecommunications Management Network
ITU-T variation of FCAPS - See above - specially targeted towards Tele Communication Networks
PPDIOO
Also called Cisco Lifecycle Services (See drawing below)

PPDIOO Life Cycle Reference: http://mars.tekkom.dk/mediawiki/index.php/CCNP_TSHOOT_642-832/Chapter_1

Solution Steps need to follow as below:
When we check on client 1 & Client 2 desktop we are not receiving DHCP address from R4 Ipconfig ----Client will be getting 169.X.X.X
On ASW1 port Fa1/0/ 1 & Fa1/0/2 access port VLAN 10 was assigned which is using IP address 10.2.1.0/24
Sh run ------- & check for running config of int fa1/0/1 & fa1/0/2

Here we are not able to see access Vlan10 configured for Port Fa1/0/1 & Fa1/0/2
Change required: On ASW1, for configuring Access Vlan under interface fa1/0/1 & 1/0/2 we have to enable command switchport access vlan 10
So in ticket Answer to the fault condition will be as:
